Application Scenarios:

Defibrillator is a medical device that utilizes a stronger pulse current through the heart to eliminate arrhythmia and restore sinus rhythm, and it is a necessary first aid equipment in all hospital departments. Defibrillation is one of the important steps for performing CPR

Products advantage:

Battery Level Indicator：To monitor the battery real time
Biphasic Technology：With impedance compensation More effective Less Energy and less hurt to the heart
Internal Thermal Printer：50mm integrated thermal recorder
Data Storage：65 hours of all measured parameters
Paddle：Charging and shocking can be easily operated through according buttons；Quickly converted from adult to pediatric by removing the outer surface

Technical Specifications:

Display Type: 8 inch high resolution LCD display
Sweep Speed: 25mm/sec
Information: HR, Lead/Pads, On/Off Alarm, SpO2, AED Functions and Prompts, Alarm Selection and Limits, Delivered Energy.
Defibrillator
Waveform: Biphasic
Charge Time: Less than 7 seconds with a new fully charged battery.
Energy Display: Monitor display indicates both selected and delivered energy.
Charge Prompt Type: Voice and visual prompts.
Electrode Impedance Measurement Range: 0-250 ohms.
ECG Monitoring
Patient Connection: 5-lead ECG cable, or 3-lead ECG cable, paddles.
Lead Selection: Displayed on monitor, paddles, , II, III, AVR, AVL, AVF, V.
ECG Size: 0.25, 0.5, 1, 1.5, 2, 4 cm/mV display on monitor.Heart Rate:20-300BPM.
Heart Rate Alarm: On/Off displayed on monitor, user-selectable
Smart Alarms: Beeper/voice prompts indicate shockable rhythm.
Battery
Type: Rechargeable,Ni-MH battery,12V.
Operating Time: For a new, fully charged battery: 60 defibrillator discharges at maximum energy, or 3 hours minimum of continuous ECG monitoring.
Additional parameters will effect operating time with different functions.
AED Mode
AED Function: Auto analyze and charge X3 with programmable auto energy level selection.
screen prompts.and voice prompts.
Shockable Rhythms: Ventricular fibrillation with amplitude >=200UV, ventricular tachycardia with rates >=140bpm,and QRS complex wave duration >=140ms.
Charge Control: Control on device front panel, press key on paddle.
Prompts: Voice and visual prompts.
