Application Scenarios:

A cardiac defibrillator (AED) is an emergency medical device used to deal with sudden cardiac arrest. It analyzes the patient's heart rhythm and restores the heart's normal rhythm with an electric shock if needed

Products advantage:

Three-step defibrillation process
Two-button operation
Extensive voice and visual prompts for the operator
Biphasic energy output
Lock-out protection to prevent inadvertent defibrillation
Automatic Self-test: Daily battery condition test& Monthly AED whole inter system test

Technical Specifications:

Defibrillator
Output：    Biphasic Truncated exponential
Energy Sequence：    150,150,200J
Charge Time：    8 sec. to 150J；10 sec. to 200J (New battery)
Analysis Time：    9 sec.
The maximum time from the initiation of rhythm analysis to readiness for discharge with a new battery：    Less than 20 seconds
The maximum time from the initiation of rhythm analysis to readiness for discharge after 6 shocks：    Less than 25 seconds
The maximum time from initially switching power on to readiness for discharge    Less than 30 seconds：
Audible Prompt：    22 audible prompts
Visual Prompts：    LED prompts
Controls：    Two buttons-on/off, shocks
Output Energy Accuracy：    ±15% into any impedance from 25 to 175Ω
The Maximum Voltage：    1200±50V
Output disabled when the patient impedance is outside limits：    20Ω to 200Ω
Battery
Part NO：    CR123A-4x2
Non-rechargeable：    2.8Ah
Capacity：    100 discharges at 200 Joules  or 120 discharges at 150 joules
Shelf Life(25℃±15℃）：    5 years standby(after installation)
Physical
Dimensions：    303x216x89mm
Weight：    2.0 kg
Operating Temperature：    0℃ to 40℃
Operating Humidity：    Relative humidity between
30% and 95% (non-condensing)
Storage Temperature(without battery)：    -20℃ to 55℃
Storage Humidity(without battery)：    Up to 93%(non-condensing)
