FND-8000D Defibrillator

Defibrillator

FND-8000D Defibrillator-1

Application Scenarios:

Defibrillator is a medical device that utilizes a stronger pulse current through the heart to eliminate arrhythmia and restore sinus rhythm, and it is a necessary first aid equipment in all hospital departments. Defibrillation is one of the important steps for performing CPR.

Technical Specifications:

Display
Screen Type:High-resolution display, TFT colour display
Screen Size: 7 inches (17.7cm) diagonally
Sweep Speed: 12.5/25/50mm/sec
Information: Heart Rate, Lead, Alarm On/Off, Delivered Energy
Resolution:800X480
ECG
Patient Connection: 3-lead ECG cable, or 5-lead ECG cable, paddles.
Lead Selection: Displayed on monitor, paddles, I, II, III,AVR, AVL, AVF, V.
ECG Size: 2.5,5, 10, 20, 30 mm/mV display on monitor.
Heart Rate: 20-350BPM.
Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation
Defibrillator
Waveform: Biphasic
Defibrillator type: Manual External Synchronous/Asynchronous Defibrillation.
Charge Time: Less than 10 seconds to 360 Joules
Energy Display: Monitor display indicates both selected and delivered energy.
Charge Prompt Type: Voice and visual prompts.
Energy Selection: Selectable at 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joules
Standard Adult/Pediatric Paddles: Reusable external adult paddles (pediatric paddles integrated)
Battery Description
Standard Type: Li-ion battery Li1104c 11.1Vdc 4000mAh X2
Standard Capacity: Up to 10 hours ECG monitoring or 60 full-energy discharges.
Low Battery Indicator: Flashing low battery icon on display and Bat Indicator on the panel of defi-monitor be on
Recharge Rate: 80% in 3 hours. 100% in 5 hours.
Built-in Recorder
Paper: 50mm thermal.
Printing Method: High-resolution, thermal print head.
Record date, time ,sweep speed, waveform gain, heart rate, energy (joule) and ECG waveform
Print mode
HR exceed limits alarm recording
Auto timed recording
Real-Time Recording
Defibrillation discharge trigger recording
Power
AC-DC dual-use: Use the batteries,AC100V~240V,50/60 Hz.
Vehicle Voltage(Option): DC 12V

FND-8000C Defibrillator-5 FND-8000C Defibrillator-6 FND-8000C Defibrillator-7 FND-8000C Defibrillator-8

Accessory Standard
Main set	1Pcs
Finger SpO2 probe	1Pcs
Adult NIBP cuff	1Pcs
Reusable NIBP Cuff Hose	1Pcs
Temp probe	1Pcs
ECG cable	1Pcs
ECG electrode	10Pcs
Power supply cable	1Pcs
11.1V Li-ion battery	2Pcs
Printing paper	2Pcs
Fuse 5A	2Pcs
Packing list	1Pcs
Certificate	1Pcs
User's manual	1Pcs
